Specification
- Dock Arm Capacity : 400kg at 20~40*m (*그 외도 가능)
- Safety working load(SWL) : 400kg
- Travelling speed : 0~25m/min
- Slewing speed : 0~15m/min at basket
- Slewing angle : 180° limited
- Over load : over the 500kg at basket
- Electric source : AC415V, 50Hz
- Hydraulic pressure(working) : abt. 230kg/㎠
